The Explorer grow light fixture is designed for a full grow cycle with maximized red for increased photosynthesis. Ideal for 2’ x 4’ tent environments for increased consistency and yield.

FEATURES

  • Efficacy up to 2.56 Micromoles / J @120 VAC
  • Industry Leading Horticulture LEDs
  • RJ Port for Plug and Play Control Systems
  • Fast and Easy Installation
  • 7 Year Limited Warranty on Fixture
  • 8 Year Limited Warranty on Driver
SPECTRUM AND EFFICACY
PPF Efficacy: 2.56 at 120VAC
Photon Flux (µmol/s) (400-700nm): 870
Photon Flux Blue (µmol/s) (400-500nm): 161
Photon Flux Green (µmol/s) (500-600nm): 355
Photon Flux Red (µmol/s) (600-700nm): 355
Total Blue/Red - Energy Bands: 516
% Blue: 18.51%
% Green: 40.76%
% Red: 40.73%
POWER
Power Consumption: 340W AC
Driver: Sosen
Power Factor: >0.95
Surge Protection: 6 KV
120V: 2.90 A
208V: 1.75 A
240V: 1.51 A
277V: 1.31 A
DIMENSIONS
Fixture Size (driver mounted on the fixture): (L) 43.7” x (W) 22” x (H) 4.1”
Fixture Size (without driver): (L) 43.7” x (W) 22” x (H) 1.6”
Power Supply Dimension: (L)18.7” X (W) 4.4” X (H) 2.4”
Driver Net Weight: 6 lb.
Fixture Net Weight: 6 lb.
OTHER
Mounting Height >6” above canopy
Beam Angle 120 Degree
Input Voltage 100 - 277 VAC
Manual Dimming Knob Yes
Built In Control Ports Yes
Standard Power Cord (Extensions available) AWG 18, 6 Foot
Standard Plug 120 VAC - NEMA 5-15P
Substitute Plugs (Upon request at order) 240 VAC, 277 VAC, Pigtails
Adjustable Height Hanging Kit Included Yes
Fixture Warranty 7 Years Limited
Driver Warranty 8 Years Limited
ETL Safety Certified Conforms to UL 1598:2018 Ed.4Certified to CSA C22.2#250.0:2018 Ed.4*ETL Safety Certified No. 5020070
