Neocision Spectra Pro fixtures feature a 18.5% blue spectra and 40.7% red spectra with a peak at 660nm for your flowering plants. This unique spectra mix creates stronger plants for nutrient uptake with maximized red for increased photosynthesis. Get increased yields, quality bud formation and high rates of cannabinoid production levels.

FEATURES

  • Efficacy up to 2.58 Micromoles / J @ 120 VAC
  • Industry Leading Horticulture LEDs
  • RJ Port for Plug and Play Control Systems
  • Folding Design for Fast and Easy Installation
  • 7 Year Limited Warranty on Fixture
  • 8 Year Limited Warranty on Driver
SPECTRUM AND EFFICACY
PPF Efficacy: 2.58 at 120 VAC
Photon Flux (µmol/s) (400-700nm): 1751
Photon Flux Blue (µmol/s) (400-500nm): 324
Photon Flux Green (µmol/s) (500-600nm): 714
Photon Flux Red (µmol/s) (600-700nm): 713
Total Blue/Red - Energy Bands: 1037
% Blue: 18.51%
% Green: 40.76%
% Red: 40.73%
POWER
Power Consumption: 680W AC
Driver: Sosen
Power Factor: >0.95
Surge Protection: 6 KV
120V: 5.72 A
208V: 3.44 A
240V: 2.98 A
277V: 2.58 A
DIMENSIONS
Fixture Size (driver mounted on the fixture): (L) 43.9” x (W) 43.9” x (H) 4.1”
Fixture Size (without driver): (L) 43.9” x (W) 43.9” x (H) 1.6”
Power Supply Dimension: (L)23” X (W) 6.5” X (H) 3”
Driver Net Weight: 10.1 lb.
Fixture Net Weight: 13.8 lb.
OTHER
Mounting Height >6” above canopy
Beam Angle 110 Degree
Input Voltage 100 - 277 VAC
Manual Dimming Knob Yes
Built In Control Ports Yes
Power Cord Length (Extensions available) AWG 16, 6 Foot
Standard Plug 120 VAC - NEMA 5-15P
Substitute Plugs (Upon request at order) 240 VAC, 277 VAC, Pigtails
Adjustable Height Hanging Kit Included Yes
Fixture Warranty 7 Years Limited
Driver Warranty 8 Years Limited
ETL Safety Certified Conforms to UL 1598:2018 Ed. 4Certified to CSA C22.2#250.0:2018 Ed.4*ETL Safety Certified No. 5020070
DLC Listed Yes
