SPYDR 2x is an early-development stage top-lighting solution for commercial horticulture cultivation, or a full-cycle top-lighting solution for home hobbyists cultivating without CO2 supplementation at ambient conditions around 400 ppm.

SPYDR 2x is comparable to the previous generation’s SPYDRx and delivers an average of 550 µmol/m2/s of highly-uniform light over a 4’x4’ area at only 6” above canopy.

  • Light Output PPF: 860 µmol/s
  • Efficacy: 2.51 µmol/J @ 277 AC
  • AC Input Power: 342W @ 277V AC
  • Certifications: UL 8800, UL 1598 Wet Location, DLC
  • Warranty: 5 Year Standard Warranty
  • Spectrum: PhysioSpec Indoor™
Part Length Width Height Weight
SPYDR 2x 47”
Light Fixture
47”
1194 mm
42.80”
1087 mm
1.26”
32 mm
16.7 lbs
7.6 kg
PSE Power Supply
342W AC
21.87”
555 mm
6.24”
159 mm
2.88”
73 mm
8.2 lbs
3.7 kg


SPYDR 2x fixtures are suitable for operation in still air ambient temperatures from -10°C (-23°F) to 35°C (95°F). SPYDR 2x operating temperatures range between 25°C (77°F) and 30°C (86°F) above ambient air temperature. Please note; when mounting SPYDR fixtures, a 1 inch gap or greater must be present between the top of the fixture and the surface it is mounted under to enable adequate air flow.

Fluence recommends at least one ft3/S of airflow to ensure efficient cooling. Proper air flow will also increase the maximum suitable operating temperature and help extend lifetime of system.
