Cultivating dense canopies in a commercial-scale, vertical environment presents an interesting lighting challenge. HID lamps have the power, but excessive heat rules them out. Early-generation LED fixtures alleviate the heat issue, but fall short on photon delivery. Right in the sweet spot is where we designed the F1V luminaire. Plenty of power. No thermal excess.
The F1V form factor is a dual-purpose design. It utilizes passive cooling to keep the diodes operating at peak efficiency. It also disperses heat so efficiently that you’ll be able to bring your ambient room temperatures up, driving critical RuBisCO reactions closer to their full potential for more growth.
Uniform photon density is key to predictable crop schedules. Tell us your room dimensions and desired PPFD and we’ll create your custom layout using complex modeling software. When we’re finished you’ll be growing in an environment with uniform PPFD levels. No hot spots. No cool spots. Just precision.
Light Source: Samsung LEDs
PPF: 2,800 μMol/s
Fixture Efficacy* (100% - 50% power)*: 2.8-2.9 μMol/J
Input power: 1000W
Input voltage: Options up to 480V
Fixture dimensions: 42.0L x 46.5W x 4.6H in
Weight: 38 lbs
Thermal management: Passive
BTUs/ hour: 3,412
Lens angle: 100°
Control interface: Wall-mounted OLED panel
L90: 50,000 hours
Power supply rating: 100,000 hours
Certifications: UL1598 Damp location & IP55, CE
Communication protocol: CAN or BACNet
Mounting: Universal Hanging
